Plywood Core Types

sample_combination_core-e1435872330723

Combination Core

sample_combination_core-e1435872330723

There are two types of Combination Core construction.

The first type consists of a center veneer core and a crossband veneer on both sides of the center with a layer of MDF, particleboard, or hardboard under the face and back veneer.

The second type consists of an oriented strand board or wafer board center with a veneer crossband on both sides, under the face and back veneer.

Combination Core Plywood can be used when the project calls for consistent flatness and good screw-hold ability, without the weight of an MDF or particleboard core.

sample_lumber_core-e1436218315818

Lumber Core

sample_lumber_core-e1436218315818

Lumber edge-glued into a solid slab is considered Lumber Core.

Lumber Core plywood is most often found in the construction of import panels, usually only 18mm thickness panels.

Lumber Core plywood consists of a face & back veneer, then a layer of crossband veneer, with the edge-glued lumber in the center.

Lumber Core plywood should be used for the bending strength and screw-hold ability. The ability of Lumber Core plywood to bounce back makes it an excellent choice when constructing long or wide shelves in cabinets or closet doors.

sample_mdf_core-e1435872706821

MDF Core

sample_mdf_core-e1435872706821

Medium Density Fiberboard Core has the most uniform thickness and consistency of any panel core.

The face and back veneer are glued directly to the MDF Core without the need for a crossband veneer.

The consistency in thickness and flatness makes MDF Core panels the preferred choice for 32mm construction.

sample_particleboard_core-e1436218482535

Particleboard Core

sample_particleboard_core-e1436218482535

Particleboard Core panels are constructed similar to MDF Core panels, with the face & back veneers glued directly to the core.

Particleboard Core lays flat like MDF, but does not have the screw-hold strength of other cores.

Particleboard Core is the least expensive of all core types.

sample_veneer_core-e1435872821263

Veneer Core

sample_veneer_core-e1435872821263

Veneer Core plywood consists of a center veneer and crossband veneers alternately layered on both sides of the center to the desired thickness producing an odd number of veneers for the core.

The weight-bearing strength of Veneer Core plywood is excellent along with its bending strength and screw-hold ability.

Veneer Core panels are lighter in weight than any other core type.

See also Plywood Core Attributes: Fir vs Poplar.
